Minimum light level low end shall be adjusted to optimize performance. Wiring diagram using a power pack.
0 10 Volt Dimming Wiring Diagrams Bmw Yahudi7 Vovbernheze Nl
0 to 10 volt dimmer wiring diagram. 0 10 v 30 ma switch. Gray dimmer lead to gray connection on ballast. Decorator 0 10 volt dimmer project name. 0 10 v preset dimmer for use with. A wiring diagram is a simplified standard photographic depiction of an electric circuit. Electrostatic discharge tested.
Collection of 0 10 volt dimming wiring diagram. 0 10v class 1 and class 2 wiring overview 0 10v ballasts and drivers are connected together by a 2 wire low voltage bus that is suitable for class 1 or class 2 wiring installations. 24 v 100 ma performance power failure memory. Single pole wiring diagram bk black thumbwheel slider top v iolet gray vt gy single pole wiring diagram 3 way wiring diagram wiring diagrams certifications compliances. It shows the elements of the circuit as streamlined forms and the power and signal connections between the devices. Volt lighting control devices package contents and parts identification figure a operation the volt low voltage lighting control.
0 10 volt dimmers produce varying light intensities from 10 to 100. Using 0 10v dimmers with led power supplies. 0 10v dimming wiring diagram valid wiring diagram for dimmer switch 0 10 volt dimming wiring diagram. Enviroment for indoor use only. Wiring diagram not merely offers in depth illustrations of everything you can do but also the methods you should stick to while performing so. 0 10v dimming wiring diagram 0 10v dimmer switch leviton ip710 lfz or equal for other types of dimming control systems consult controls manufacturer for wiring instructions switched hot black switched hot red typical low voltage dimming wires purple gray typical electrical panel hot black typical 120v or 277v 60 hz neutral white.
0 advance mark vii v electronic dimming ballasts lutron eco 10 volt option wire controls according to the appropriate wiring diagram shown inv preset dimmer for use with. Proceed to step 5. The design of many dimming switches causes the fixtures to continually run albeit at a low power even if the dimmer is turned all the way down. Wiring diagrams dimming with onoff control wiring diagram using relay 0 10 v ballastdriver white white red red red. Wiring diagram 1 insulating label green ground black white red hot black neutral white line 120277vac 60hz dimmer gray yellow to lamps red blue 0 10 vdc ballast yellow red 1 3 7 matching remote additional neutral wire 2 dimmer 2 3 4 red violet white yellowred. Black neutral yl line 120v ac 60 hz green or bare white hot load figure 1.
This application note explains how both class 1 and 2 wiring are made and how they both meet national electric code nec regulations. 0 10 volt lighting control devices package contents and parts identification figure a operation the 0 10 volt low voltage lighting control provides dimming control for 0 10 volt compatible led drivers fluorescent ballast and hid ballast. Operating temperatures 0 c 32 f to 40 c 104 f.
