Wiring a new plug isnt difficult but its important to get the hot and neutral wires connected to the proper prongs. Replacing the male or female plug on a cord is far less expensive than replacing the entire cord and its easy to do.
Details About Heavy Duty 30a Rv Replace Male Plug Connector For Camper 4wd Trailer Power Cord
Male plug wiring diagram. Read below i am demonstrating this on a cord to my asteroids arcade machine that had a really. When replacing a three prong plug connect the black wire in the cord to the brass terminal screw the white wire to the chrome terminal and the green or bare wire which is the ground wire to the green ground screw in the plug. When wiring a trailer connector it is best to wire by function as wire colors can vary. The worry is that a miswired plug poses a fairly serious shock hazard. We have an excellent wiring diagram on our website i will provide you a link so you can look at it. To see if a cord is working properly plug it into a three prong receptacle.
Then fit a plug in circuit tester onto the cords other end. Reassemble the replacement plug and tighten the screws holding it to the cord. The key is to make sure you connect the wires to the proper terminals in the plug. Three prong plugs have a hot wire a neutral wire and a ground wire. Eletric end plug replacement httpsamznto2hn6chd how to replace a 3 prong electrical plug. If you are looking at the inside of the trailer connector where the wires mount to the terminals starting at the top and rotating clockwise.
Youll know if your plug is too small because the wires wont fit on the terminals and the casing wont fit around the cord sheathing. The danger isnt fire. The testers lights will indicate whether the wires are hooked up correctly and the cord is grounded. The main thing to remember is to buy a plug designed for the wire gauge of the cord.
