Thermal overload relay connection diagram. The working principle of thermal overload relay is quite simple but interesting. It offers reliable and fast protection for motors in the event of overload or phase failure. The wiring diagram of an overload relay is shown below and the connections of an overload relay symbol may seem like two opposite question marks otherwise like s symbol. Although there are several types of overload relays available in the market however the most frequent type of relay is the. The overload relay connection diagram underneath shows the power and control connection diagram of the overload relay in a dol configuration. 2 days ago i wired 380 to 440 volts contactor for a 3 phase motor and save these images of contactor in pc.
Large electric motors can be protected from overcurrent damage through the use of. Fill up the following data of relay under test. In a wiring diagram the symbol for overload contacts may look like two opposed question marks or an s. A relay type b relay range c max. An adjustment dial located on the unit allows the ampere trip settinga manual test button. A thermal overload relay works in the.
This type of overload relay uses two different types of metal strips that are bonded together and expand at different rates. A contactor is a large relay usually used to switch current to an electric motor or another high power load. Thermal overload is widely used for motor protection. Overload relay connection diagram. Back up fuse rating 2. Contactor wiring and i hope after this post you will be able to wire a 3 phase motor i also published a post about 3 phase motor wiring with magnetic contactor and thermal overload relay but today post and contactor wiring diagram is too simple and easy to learn.
Basically thermal overload relay is an overcurrent protection of the simplest type. Though there are different types of overload relays the most common type is the bimetallic thermal overload relay. Almost all the industries rely on the electric motor to control its processes and production. Dol starter control and power wiring by using a fuse contactor overload relay motor. Easy and simple wiring diagram to make you learn easily watch the video and subscribe my youtube channel air. Its is important to.
The device has trip class 10a. Every motor must be protected from all possible faults to ensure prolonged and safe operation as well as time loss caused due to breakdown. The overload relay workingfunction is discussed below. Ta25du 40 thermal overload relay. The ta25du 40 thermal overload relay is an economic electromechanical protection device for the main circuit. As an example if we have to select the range of overload relay for a motor with a full load current of say 10 amperes it should be from 7 to 12 amperes or as near to it as possible.
Figure below shows a typical thermal overload relay. Read more thermal overload.
