The white wire between switches is not being used as a neutral. Traveler wires are interchangeable.
Wiring Diagram For Three Way Switches With Pilot Light
Wiring diagram of a 3 way switch. In the above diagram the white wire must be re identified as a hot wire at each switch location. Wiring a 3 way light switch. Pick the diagram that is most like the scenario you are in and see if you can wire your switch. Wiring a 3 way light switch is certainly more complicated than that of the more common single pole switch but you can figure it out if you follow our 3 way switch wiring diagram. A 3 wire nm connects the traveler terminals of the first and second 3 way switch together. The black line wire connects to the common terminal of the first 3 way switch.
3 way switch wiring diagram. This electrical wiring diagram shows power into light switch box 1 wire to light from switch box 1 and from switch box 1 to three way light switch box 2. With a pair of 3 way switches either can make or break the connection that completes the circuit to the light. Typical 3 way switch wiring nm cable. 3 way switch wiring diagram with line and load in the same switch box. In this diagram the electrical source is at the first switch and the light is located at the end of the circuit.
Take a closer look at a 3 way switch wiring diagram. Three wire cable runs between the switches and 2 wire cable runs to the light. This might seem intimidating but it does not have to be. An example of three way switch wiring with the line and load in the same 4 square electrical box. Wiring diagram 3 way switch with light at the end. With these diagrams below it will take the guess work out of wiring.
Wiring diagram for a 3 way switch one of the many wiring diagrams showing different methods of wiring a three way switch circuit. In the 1st diagram below a 2 wire nm cable supplies power from the panel to the first switch box. The black and red wires between sw1 and sw2 are connected to the traveler terminals.
